Alubos
Alubos 1300
Model #
ABP 1300-1000
Part #
84130000
Type
Extrusion
Description
Closed Extrusion only, satin black powder
coated, fine texture Aluminum (sold by the meter)
ABPH 1300-1000 84136000
ABPU 1300-1000 84137000
Extrusion
Extrusion
Horizontally Split Extrusion only, satin black powder
coated, fine texture Aluminum (sold by the meter)
Extrusion open on one side, satin black powder
coated, fine texture Aluminum (sold by the meter)
Accessories
Model #
ABM 1300 AL
Part #
84132000
Type
Lid
Description
Mounting lid, satin black powder-coat
Drawing
Page #
17-103
fine texture, aluminum profile cap
ABM 1300 SAL
84134000
Lid
Mounting lid, satin black powder-coat
17-103
fine texture, aluminum hinged cap
ABD 1300
84131000
Lid
End lid, satin black powder-coated fine
17-103
texture, aluminum
ABPU 1300 FP2
DI 1300-RFI
DI 1300-5002
DI 1300-3000
DI 1300-1021
DI 1300-6000
AB–WL
84138000
84201615
84201614
84201616
84201612
84201613
84005000
Lid
RFI Gasket
Gasket
Gasket
Gasket
Gasket
Bracket
Slide in lid, sold by the meter, unpainted
? Seal, black, 10 piece pack
? Seal, ultramarine, 10 piece pack
? Seal, flame red, 10 piece pack
? Seal, yellow, 10 piece pack
? Seal, patina green, 10 piece pack
Wall Bracket
17-103
17-103
17-103
17-103
17-103
17-103
17-108
ABP= Closed profile, ABPH= Horizontally split profile
ABPU= Extrusion open on one side
Unpainted extrusions and lids are special order.
Accessories include black seals, screws, & screw covers.
3-28
ABP 1300
Closed profile
ABPU 1300
Open extrusion
ABPH 1300
Horizontally split profile
The All-Around Solution
